Product Data Sheet

Main Features
Manufacturer/Supplier: Tyco Electronics
Manufacturer Part Number: E381864
Manufacturer Website Address: www.tycoelectronics.com
Brand Name: Elo
Product Model: 1937L
Product Name: 1937L Open-frame Touchscreen LCD Monitor
Marketing Information: The 1937L Open-frame Touchscreen LCD Monitor delivers a cost-effective touch solution for OEMs and systems integrators, and complements the expanded family of Elo touch solutions for gaming and amusement, retail self-service and kiosk applications. This compact touchmonitor is "designed for touch," with proven expertise and reliability built-in, not added as an afterthought by altering an existing monitor.
Product Type: Open-frame LCD Touchscreen Monitor
Screen Size: 19"
Screen Mode: SXGA
Maximum Response Time: 10 ms
Aspect Ratio: 5:4
Horizontal Viewing Angle: 160°
Vertical Viewing Angle: 155°
Mount Type: Bracket-mountable
Maximum Resolution: 1280 x 1024
Standard Refresh Rate: 60 Hz
Color Supported: 16.7 Million Colors
Contrast Ratio: 800:1
Brightness: 250 Nit
Touchscreen: Yes
Touchscreen Type: Surface Acoustic Wave
USB: Yes
VGA: Yes
Operating Power Consumption: 38 W
VESA Mount Compatible: Yes
VESA Mount Standard: 75 x 75, 100 x 100
Color: Steel, Black
Height: 13.50"
Width: 16.30"
Depth: 2"
Weight (Approximate): 11.46 lb
